Forklift Starters - Today's starter motor is normally a permanent-magnet composition or a series-parallel wound direct current electrical motor along with a starter solenoid mounted on it. As soon as current from the starting battery is applied to the solenoid, mainly through a key-operated switch, the solenoid engages a lever which pushes out the drive pinion which is situated on the driveshaft and meshes the pinion using the starter ring gear which is seen on the engine flywheel.
The solenoid closes the high-current contacts for the starter motor, which starts to turn. When the engine starts, the key operated switch is opened and a spring within the solenoid assembly pulls the pinion gear away from the ring gear. This action causes the starter motor to stop. The starter's pinion is clutched to its driveshaft by means of an overrunning clutch. This allows the pinion to transmit drive in only a single direction. Drive is transmitted in this manner through the pinion to the flywheel ring gear. The pinion remains engaged, for example for the reason that the operator did not release the key when the engine starts or if the solenoid remains engaged for the reason that there is a short. This causes the pinion to spin independently of its driveshaft.
This aforesaid action prevents the engine from driving the starter. This is an essential step in view of the fact that this particular type of back drive would enable the starter to spin very fast that it will fly apart. Unless modifications were made, the sprag clutch arrangement will preclude the use of the starter as a generator if it was utilized in the hybrid scheme discussed earlier. Typically a standard starter motor is intended for intermittent use which would preclude it being used as a generator.
Thus, the electrical parts are designed to be able to work for just about less than thirty seconds in order to avoid overheating. The overheating results from too slow dissipation of heat because of ohmic losses. The electrical parts are designed to save cost and weight. This is the reason most owner's instruction manuals utilized for automobiles recommend the operator to pause for at least 10 seconds right after every 10 or 15 seconds of cranking the engine, if trying to start an engine which does not turn over at once.
The overrunning-clutch pinion was launched onto the marked during the early 1960's. Before the 1960's, a Bendix drive was used. This drive system functions on a helically cut driveshaft which consists of a starter drive pinion placed on it. Once the starter motor starts turning, the inertia of the drive pinion assembly allows it to ride forward on the helix, therefore engaging with the ring gear. As soon as the engine starts, the backdrive caused from the ring gear enables the pinion to exceed the rotating speed of the starter. At this instant, the drive pinion is forced back down the helical shaft and hence out of mesh with the ring gear.
The development of Bendix drive was developed during the 1930's with the overrunning-clutch design referred to as the Bendix Folo-Thru drive, developed and launched in the 1960s. The Folo-Thru drive consists of a latching mechanism together with a set of flyweights within the body of the drive unit. This was better because the typical Bendix drive utilized to be able to disengage from the ring as soon as the engine fired, even though it did not stay running.
The drive unit if force forward by inertia on the helical shaft once the starter motor is engaged and starts turning. After that the starter motor becomes latched into the engaged position. As soon as the drive unit is spun at a speed higher than what is attained by the starter motor itself, like for example it is backdriven by the running engine, and next the flyweights pull outward in a radial manner. This releases the latch and enables the overdriven drive unit to become spun out of engagement, hence unwanted starter disengagement can be avoided before a successful engine start.
